Garnet Swinger Guitar Amplifier.

This is the amplifier The Peasant uses for making music. Synthesizers sound much better through tubes!

Schematic

Line-Powered Tube Amplifier.

Here is a small mono tube amp that The Peasant picked up cheap at a flea market. This looks like a good unit to drive a reverb. Note the selenium rectifiers and lack of any power transformer. If you have any information about this unit and from what it was removed, please send me a note!

Schematic

Tube Circuits.

Here is a DC amplifier circuit for raising lower solid-state synth voltage signals up to tube level voltages.

Schematic


Here are a couple of tube flip-flop circuits.

Schematic 1 Schematic 2


And a tri-state flip-flop circuit. Thank you to Danial Stocks for this circuit!

Schematic


SN76477N Gated Noise Generator Circuit.

Here is a circuit The Peasant put together to generate the "snares" sound in a percussion synthesizer. A basic trigger and output circuit are included for stand-alone use.

Schematic

Diode Matching Circuit.

Here is a circuit for matching diode voltage drops at different currents. Useful for building balanced modulators.

Schematic

Construction Articles

Transistor Theremin

Page 1 Page 2 Page 3 Page 4 Page 5 Page 6

Bullet SE-01 SN76477N Sound Effects Kit

Page 1 Page 2 Page 3 Page 4 Page 5 Page 6

Page 7 Page 8 Page 9 Page 10 Page 11 Page 12

Page 13 Page 14 Page 15 Page 16 Page 17 Page 18

Page 19 Page 20 Page 21 Page 22 Page 23

Data Sheets

George A. Philbrick GAP/R K2 Series Vacuum Tube Op Amp Applications Manual
Page 1 Page 2 Page 3 Page 4 Page 5 Page 6

Page 7 Page 8 Page 9 Page 10 Page 11 Page 12

Page 13 Page 14 Page 15 Page 16 Page 17 Page 18

Page 19 Page 20 Page 21 Page 22 Page 23 Page 24

Page 25 Page 26 Page 27

MN3001 SAD IC
Page 1 Page 2

MN3002 SAD IC
Page 1 Page 2 Page 3 Page 4

SN76477N Sound Generator IC
Page 1 Page 2 Page 3 Page 4 Page 5 Page 6

Page 7 Page 8

Miscellaneous

Aries Music 1977 catalog

Page 1 Page 2 Page 3 Page 4 Page 5 Page 6

Page 7 Page 8 Page 9 Page10 Page 11 Page 12

Page 13 Page 14 Page 15 Page 16

And for you beginners, a bit of a humourous rant from Harry Bissell regarding the importance of getting an oscilloscope for troubleshooting, as well as a good explanation of decoupling. Thanks, Harry!

scopes.txt decouple.txt
